Technical details

The Quest carbon costs € 7950

The Quest comes ready-to-ride, including light system (12V battery, charger, turning signal lights, Cyo 80Lux, horn, dashboard light and breaking light), 3x11 speed, velomobile bag, bicycle computer, Ventisit mat, foam cover, SPD pedals, bell, air pump, spare tyre and tyre repair set, tools and 19mm rear axle.

The Quest is made of carbon composite, incl. rear swing arm.

Technical specifications
Length 2,85 m
Width 0,765 m
Height 0,87 m
Weight 28 kg ready-to-ride, including battery
Turning Circle 11 m (depending on front tyre size)
Seat angle 35 - 40º (adjustable)
Colour
  • white, yellow, orange, red, blue, turquoise, green or black
  • on request: metalic colour - €500
 colours
Electrical Equipment
  • B&M Cyo 80 Lux (adjustable from inside)
 Quest B&M Lumotec IQ CyoQuest B&M Lumotec IQ Cyo
  • LED tail light and brake light in rear
 Quest rear light
  • Li-ion 12V 2,6Ah battery/battery charger, Non EU customers recieve no battery, dashboard light
 Quest dashboard light
  • Turn signals (8x luxeon 1W LED)
 Quest signal lights frontQuest signal lights rear
  • Electric horn
 Quest horn
Cranks and chainwheels Drivline ISIS triple 53/42/30
Rear Sprockets
  • Sunrace CSRX1 11v 11-32 / 11-36
  • some other shimano (compatible) 11v sprockets are possible
Derailleurs Front Sram X5, Rear Sram GX 11 speed
Chain KMC X11EL
Shifters Sram Trigger shift GX
Brakes
  • SA Aluminium 70mm drum brakes (single-side mounted)
  • on request: SA Aluminium 90mm drum brakes (€25)
Pedals Shimano PD-A600 (spd)
Tyres
  • front: Schwalbe Durano fold. 28-406
  • rear: Schwalbe Kojak 50-559
Spokes
  • front: Sapim 179 mm strong butted 13/14 RVS 36pc a wheel (90 mm drums 176 mm)
  • rear: Sapim 264 mm race butted 14/15/14 32pc/wheel
Rims
  • front: Gingko hollow rim, 36 holes
  • rear: Gingko hollow rim, 32 holes
Mirror
  • Busch & Müller Cycle star
 Quest mirror

On request


2nd head light
  • Busch & Müller Cyo - €100
 Quest dubbele koplamp
IQ-X 150 Lux light
  • Busch & Müller IQ-X 150 Lux - €75/pc
 Quest IQ-X 150 Lux
2nd mirror €15 Quest 2nd mirror
Mirror cone L or R in colour of velomobile - €30/pc
2nd battery €55
90mm drum brakes SA Aluminium - €25
Lift handle €10
Arm rests €35
Hitch €50
Luggage box L or R - €50/pc
Neck rest/roll €17.50/15.00/pc
Here you can find photos and more accessories.

Prices since 17-10-2019
